Molex PowerCat6 U/UTP Network Cable Cat6 4 Pair 23AWG HDPE/LSZH Violet 305M

Description

U/UTP Network Cable Cat6 4 Pair, 23 AWG, 0.550 +/-+ 0.004mm Conductor Diameter, 9.5 Ohm/100 mtr Conductor Resistance, 4 Pair, 250 MHz Bandwidth, Cat6 U/UTP Cable, Solid Bare Copper Conductor, HDPE Insulation, LSZH Sheath, Violet Sheath,-20 to 75 deg C, 305 mtr Length

Key Specifications

SKU	MODCAA-00200
Brand	Molex
Product Type	Network Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Enhanced performance 4 pair LS0H cable Category 6 compliant Colour coded for ease of termination
Standard Pack Size	1
UNSPSC Class	26121600
UOM	BX
Vendor Product	CAA-00200
Cable Type	Cat6 U/UTP
Conductor Diameter	0.550 +/-+ 0.004mm
Conductor Resistance	9.5 Ohm/100 mtr
Conductor Size	23 AWG
Conductor Material	Solid Bare Copper
Frequency Bandwidth	250 MHz
Insulation Material	HDPE
Pair Count	4 Pair
Sheath Colour	Violet
Sheath Material	LSZH
Temperature	-20 to 75 deg C
