Legrand Cartridge Fuse HRC without Indicator Clip In Ferrule 125A 500VAC 100kA Class aM 22x58mm
Loading...
Description
Cartridge Fuse HRC without Indicator Clip In Ferrule, 500 VAC, 125 Amp, Interrupt Capacity: 100 kA, Class aM, 22mm Diameter, 58mm Length, Clip In Ferrule Tag, Cylindrical, Ceramic Body
Key Specifications
| Barcode (EAN-13) |
3245060150976
|
|---|---|
| SKU |
LEG15097
|
| Brand |
Legrand
|
| Product Type |
Fuses
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | 15097 |
| Current | 125 Amp |
| Diameter | 22mm |
| Interrupt Capacity | 100 kA |
| Material | Ceramic |
| Shape | Cylindrical |
| Tag Type | Clip In Ferrule |
| Voltage | 500 Volt AC |
| Utilisation Category | Class aM |
