Cabac In-Line Splice Insulated Double Grip 2.5-6mm 1C Yellow 25 Pack

$Cabac\Cabac_ILS5_5DG.jpg$

Description

In-Line Splice Insulated Double Grip, 2.5-6 mm, 1 Conductors, 300 Volt, 48 Amp, 1.5 kV Min. Breakdown Voltage, 200 Mpa Tensile Strength, 35% Ductile Rating, 99.5% IACS Conductivity, 1.738 micro-Ohm cm Resistivity, Funnel Entry Terminal, Annealed Copper, PVC Insulation, Yellow Insulation, Tin Electroplated, -40 to 105 deg C, 25 Pack

Key Specifications

Barcode (EAN-13)	9318674521860
SKU	CAAILS5.5DG
Brand	Cabac
Range Name	Pre-Insulated Terminals
Product Type	Splice & Bullet Connectors

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Unique funnel entry that speeds wire termination - increasing reliability High quality product - meets international standards Long term electrical integrity Full technical back up including QA
Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	ILS5.5DG
Conductive Material	Annealed Copper
Conductivity	99.5% IACS
Conductor Size	2.5-6 mm
Current Rating	48 Amp
Ductile Rating	35%
Finish	Tin Electroplated
Insulation Colour	Yellow
Insulation Material	PVC
Min. Breakdown Voltage	1.5 kV
Pack Size	25 Pack
Number of Conductors	1
Resistivity	1.738 micro-Ohm/cm
Temperature	-40 to 105 deg C
Tensile Strength	200 MPa
Terminal Type	Funnel Entry
Voltage Rating	300 Volt
