Wago Rail Terminal Block 3 Wire 1 Level 2.5mm Orange Polyamide 66

Description

Rail Terminal Block, 800 Volt, Rated Surge Voltage: 8 kV, 24 Amp, 2.5mm Conductor, 3 Conductors, Wire Strip Length: 8 to 9 mm, Wiring Format: 3 Conductor Through, Front Wire Entry, 3 Connection Points, 1 Potentials, 1 Level, Marking Position: Centre, Marking: (III / 3) ? Overvoltage category III / Pollution degree 3, Fire load: 0.123 MJ, Actuation Type: Operating Tool, DIN-35 Rail Mount, Conductor Material: Copper, Aluminium, Insulation Material: Polyamide 66, Orange, Height: 64 mm, 28 mm Width, 5 mm Depth

Key Specifications

Barcode (EAN-13)	4044918391139
SKU	WAG280-650
Brand	Wago
Range Name	Cage Clamp Series 280
Product Type	Rail Terminal Blocks

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	39121400
UOM	EA
Vendor Product	280-650
Actuation Type	Operating Tool
Colour	Orange
Conductor Material	Copper/Aluminium
Conductor Size	2.5mm
Fire Load	0.123 MJ
Current Rating	24 Amp
Depth	5 mm
Height	64 mm
Insulation Material	Polyamide 66
Marking	(III / 3) Overvoltage category III / Pollution degree 3
Marking Position	Centre
Number of Levels	1
Number of Conductors	3
Number of Potentials	1
Mounting Method	DIN Rail
Number of Connection Points	3
Rated Surge Voltage	8 kV
Wire Entry Orientation	Front
Voltage Rating	800 Volt
Width	28 mm
Wire Strip Length	8-9 mm
Wiring Format	3 Conductor Through
