Treotham Treoflex JZ Flexible Control Cable Unscreened 6 Core & Earth 0.75mm 0.3/0.5kV Copper PVC/PVC Grey

Description

Flexible Control Cable, 0.75 mm, Class 5 Copper, 0.3-0.5 kV, 6 Core + Earth, 7.7 mm Overall Diameter, Static 30.8 mm Flexible 115.5 mm Bend Radius, >20 MOhm/km Insulation Resistance, Black/Green/Yellow/White Numerals Core, PVC Insulation, PVC Sheath, Grey Sheath, Static -40 to 80 deg C Flexible -15 to 70 deg C, DIN VDE 0295 IEC 60228

Key Specifications

SKU	TRETA20.0007.07
Brand	Treotham
Range Name	Treoflex
Product Type	Flexible Control Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	TA20.0007.07
Bend Radius	Static 30.8 mm - Flexible 115.5 mm
Conductor Size	0.75 mm
Conductor Type	Class 5 Copper
Core Colours	Black/Green/Yellow/White Numerals
Insulation Material	PVC
Insulation Resistance	>20 Mohm/km
Number of Cores	6 Core + Earth
Overall Diameter	7.7 mm
Sheath Colour	Grey
Sheath Material	PVC
Standards	DIN VDE 0295 IEC 60228
Temperature	Static -40 to 80 deg C Flexible -15 to 70 deg C
Voltage	0.3-0.5 kV
