Schneider Pushbutton Actuator Only Flush Head Plastic Body k Non Illuminated Momentary Red 22mm Panel

Description

Pushbutton Actuator Only Flush Head Plastic Body, Size: 22 mm, Non-Illuminated, Unmarked, Momentary Action, Flush Head, Spring Return Reset, Tightening Torque: 0.6 N/m, IP66, IP67, IP69, IP69K, Screw Terminal Clamp/Plug-In/Printed Circuit Board/Faston, Mounting Diameter: 22 mm, Panel Mount, Plastic Housing, Plastic Bezel, Red, -40 to 70 deg C, 29 mm Height, 29 mm Width, 30 mm Depth

Key Specifications

Barcode (EAN-13)	3389110904727
SKU	TEEZB5-AA48
Brand	Schneider
Range Name	Harmony Style 5
Product Type	P/B Actuators Flush

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	ZB5AA48
Colour	Red
Depth	30 mm
Head Type	Flush
Height	29 mm
IP Rating	IP66/67/69/69K
Mounting Diameter	22 mm
Mounting Method	Panel
Operator Profile	Unmarked
Operator Action	Non-Illuminated Momentary Action
Reset Type	Spring Return
Temperature	-40 to 70 deg C
Size	22 mm
Tightening Torque	0.6 N/m
Terminal Connection	Screw Clamp/Plug-In/Printed Circuit Board/Faston
Width	29 mm
