Radox R125 High Temperature Flexible Wire Single Insulated 1 Core 1.5mm 0.6/1kV XLPO White

Description

Flexible Wire, Single Insulated, High Temperature, 1 Core, 1.5 mm, Stranded Tinned Copper, 0.6/1 kV, 30/0.25 mm Strands, 2.7 mm Overall Diameter, LSZH XLPO Insulation, Unsheathed, White Insulation, -40 to 125 deg C

Key Specifications

SKU	RADR125/1.5/WHT
Brand	Radox
Range Name	R125
Product Type	Flexible Cable High Temperature

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	High current carrying capacities Electron beam crosslinked Short circuit temperatures of up to 280 deg C with no change to material properties Easy processability (removal of insulation etc.) Excellent resistance against all conventional impregnating varnishes and potting resins Flexible Good abrasion resistance and mechanical properties Good resistance to ozone, UV and sunlight radiation Thermal Class B
Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	R125/1.5/WHT
Conductor Size	1.5 mm
Conductor Type	Stranded Tinned Copper
Insulation Colour	White
Insulation Material	LSZH XLPO
Overall Diameter	2.7 mm
Number of Cores	1 Core
Sheath Material	Unsheathed
Temperature	-40 to 125 deg C
Stranding	30/0.25 mm
Voltage	0.6-1 kV
