Panduit Crimp Lug Standard with Inspection Window Copper 150mm M16 Stud 70.5mm OAL

chevron-left
loader
Loading...

Description

chevron-down
Crimp Lug, Standard with Inspection Window Copper, 150 mm Conductor, M16 Stud, Standard Barrel, Palm Type: Straight, 70.5 mm Overall Length, 1 Hole, Wire Strip Length: 29 mm, Copper Body, Copper Conductor, Tin Plated Finish, 90 deg C, Inside Diameter: 16.5 mm, 34.5 mm Lug Length, 30.5 mm Lug Width, Crimping Die: P66, with Inspection Window

Key Specifications

chevron-down
Barcode (EAN-13)
07498376962
SKU
PANLCMA150-16-X
Brand
Panduit
Product Type
Lugs Standard Copper

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • 99.9% pure copper and tin plated to a nominal thickness of 320? in (8? m) to provide a high quality connection
  • Inspection window for standard barrel lugs allows a visually verifiable, high quality crimp
  • Rounded tongue for one hole lugs convenient for use in tight spaces
  • Internally bevelled wire entry for fast and easy installation
  • Product information marked on connector for easy selection and installation
  • Rigid stranded metric conductor
  • Class 2r
Standard Pack Size 10
UNSPSC Class 39121400
UOM EA
Vendor Product LCMA150-16-X
Barrel Type Standard
Body Material Copper
Conductive Material Copper
Conductor Size 150 mm
Crimping Die P66
Finish Tin Plated
Inside Diameter 16.5 mm
Lug Length 34.5 mm
Lug Width 30.5 mm
Number of Holes 1
Overall Length 70.5 mm
Palm Type Straight
Please Note with Inspection Window
Stud Size M16 Stud
Temperature 90 deg C
