NHP Safety Switch RCCB Type A 3P + NPole 100A 415VAC 30mA 72mm DIN 35 Rail Mount

Description

Safety Switch RCCB Type A, 415 Volt AC, 100 Amp, 50/60 Hz, 30 mA Trip Sensitivity, 72mm Module Width, 3P + N Poles, Fork/Pin Terminal, IP40 Inside/IP20 Outside, DIN 35 Rail, 10000 Cycles, 20000 Cycles Mechanical Durability, 1.5-35 mm Flexible/1.5-50 mm In/Rigid Conductor Conductor, 5 N/m Top/Bottom Tightening Torque,-25 to 55 deg C, 86mm Height x 72mm Width x 76mm Depth

Key Specifications

SKU	NHPDSRCD410030A
Brand	NHP
Range Name	Din-Safe
Product Type	Safety Switches RCCB

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	DIN-SAFE RCCBs feature 10 kA conditional short circuit rating 1P+N and 3P+N for single or three phase loads Type A, AI, F & B RCD options 30 mA sensitivity featured as standard simplifying the selection for personnel protection applications 100 mA, 300 mA and 500 mA sensitivity options Fast connection pin/fork busbar comb or busbar chassis Suits pole-covers and loadcentres
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCD410030A
Conductor Size	1.5-35 sq-mm Flexible - 1.5-50 sq-mm In/Rigid Conductor
Current	100 Amp
Depth	76 mm
Height	86 mm
Electrical Life	10000 Cycles
Frequency	50/60 Hz
IP Rating	IP40/20
Mechanical Durability	20000 Cycles
Modules	72mm
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Terminal Type	Fork/Pin
Tightening Torque	5 Nm Top/Bottom
Temperature	-25 to 55 deg C
Width	72 mm
Trip Sensitivity	30 mA
Voltage	415 Volt
