E2S SONFL1 Electronic Alarm Sounder 100 dB at 1 m 10-30 VDC Red Housing Red Lens

Description

Electronic Alarm Sounder, 10-30 Volt DC, 25 mA at 24 Volt DC Sounder, 115 mA at 24 Volt DC Beacon, 100 dB at 1mtr, LED Lamp, Light Output: 120 cd(e), 10 Tones Sound, 5 J Flash, 2 Stage Alarm, Flash Rate: 120 fpm, 4 x M20 Knockout Connection, IP66, Flame Retardant ABS, Red Housing, Red Lens, 25-55 deg C, 98mm X 172mm

Key Specifications

SKU	MECESS0051RLED
Brand	E2S
Product Type	Audible Warning Devices

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Continuous rating Automatic synchronization on multi-sounder systems Volume control Two stage alarm (DC voltage only) by reversing polarity
Standard Pack Size	1
UNSPSC Class	46171600
UOM	EA
Vendor Product	ESS0051RLED
Alarm	2 Stage
Colour	Red Housing/Red Lens
Connection Type	4 x M20 Knockout
Current	25 mA at 24 Volt DC Sounder/115 mA at 24 Volt DC Beacon
Dimensions	98 mm X 172 mm
Flash Rate	120 fpm
Flash Energy	5 J
IP Rating	IP66
Lamp Type	LED
Light Output	120 cd(e)
Material	Flame Retardant ABS
Sound Frequency	10 Tones
Temperature	25-55 deg C
Sound Level	100 dB at 1 mtr
Voltage	10-30 Volt DC
