Lapp Kabel Data Cable 2 Pair Overall Screened 0.2mm PP/AL/PVC Grey
Loading...
Description
Data Cable, 2 Pair, Overall Screened, 0.2 mm, Class 2 Tinned Copper, 7/0.2 mm Strands, 5.4 mm Overall Diameter, Conductor Resistance: 95.8 Ohm/km, Aluminium/Mylar Tape, Polypropylene Insulation, PVC Sheath, Grey Sheath
Key Specifications
| SKU |
LAP3802782.100M
|
|---|---|
| Brand |
Lapp Kabel
|
| Product Type |
Data Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 100 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 3802782.100M |
| Conductor Resistance | 95.8 Ohm/km |
| Conductor Size | 0.2 mm |
| Conductor Type | Class 2 Tinned Annealed Copper |
| Insulation Material | Polypropylene |
| Number of Pairs | 2 Pair |
| Overall Diameter | 5.4 mm |
| Screen Format | Overall Screened |
| Screen Material | Aluminium/Mylar Tape |
| Sheath Colour | Grey |
| Sheath Material | PVC |
| Stranding | 7/0.2 mm |
