IPD Modular MCB Panelboard W/250A Main Switch Wall Mount 12/36P 1&1.2mm Mild Steel Grey IP43

chevron-left
loader
Loading...

Description

chevron-down
Modular MCB Panelboard, 400 Amp, Number of Poles: 12/36, Wall, For Use With: 27mm/18mm MCBs, IP43, 1mm and 1.2mm Mild Steel, RAL7035 Grey, Epoxy Polyester Powder, 600mm Width x 200mm Depth

Key Specifications

chevron-down
SKU
IPDE43L12/36J250
Brand
IPD
Product Type
Panelboards MCB

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Suitable for indoor applications, such as inside an electrical cupboard, switchroom or mounted on an internal wall
  • Designed for 6 kA and 10 kA GE redline and contractor range protection devices
  • Full gland plate top and bottom
  • Metal lock
  • Hinged escutcheon
  • Chassis withstand rating: 25 kA/0.1s, 10 kA/1s
Standard Pack Size 1
UNSPSC Class 39121100
UOM EA
Vendor Product E43L12/36J250
Colour Grey
Current 400 Amp
Dimensions 600mm Width x 200mm Depth
Finish Epoxy Polyester Powder
IP Rating IP43
Material 1mm and 1.2mm Mild Steel
Mounting Method Wall
Number Of Poles 12/36 Pole
