Heinelec Distribution Panelboard W/250A Main Switch 48P 1.5mm Steel N12 Pastel Grey IP42

Description

Distribution Panelboard, 250 Amp, Number of Poles: 48, Flush Lockable Door, For Use With: MCCBs, IP42, 1.5mm Steel, N12 Pastel Grey, 1200mm Height x 580mm Width x 225mm Depth

Key Specifications

SKU	HEIADVS48M250
Brand	Heinelec
Range Name	Advantage
Product Type	Distribution Panelboards

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Spacious design affords more useable space Additional switchboard modules can be added to the top, bottom and sides for a modular solutions Recommended for use with either DIN mounted SFM range of MCBs 16 pole DIN knockouts for ancillary equipment Left hand hinged door (field conversion to the hand hinged) Door opens to 180 deg fitted with concealed hinges and flush, lockable catch Top and bottom removable gland plates Hinged removable escutcheon Strategic key hole mounting positions
Standard Pack Size	1
UNSPSC Class	39121100
UOM	EA
Vendor Product	ADVS48M250
Colour	N12 Pastel Grey
Configuration	SFM Type
Current	250 Amp
Dimensions	1200mm Height x 580mm Width x 225mm Depth
Door Type	Flush Lockable
IP Rating	IP42
Material	1.5mm Steel
Number Of Poles	48P
