Hager Miniature Circuit Breaker D Curve 32Amp 6kA 3Pole 3Module DIN Rail Mount

Description

Miniature Circuit Breaker D Curve, 415 Volt, 32 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 3 Module, 3 Pole, 2.8 Nm Tightening Torque, Screw Terminal, 1-25 sq-mm Flexible/1-35 sq-mm Rigid, IP20, DIN Rail Mounting, 30 deg C, 84.6 mm Height, 52.5 mm Width, 70 mm Depth

Key Specifications

Barcode (EAN-13)	3250614353260
SKU	HAGMDN332P
Brand	Hager
Product Type	Mini Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	MDN332P
Cable Size	1-25 sq-mm Flexible/1-35 sq-mm Rigid
Current	32 Amp
Depth	70 mm
Frequency	50/60 Hz
Height	84.6 mm
Interrupt Capacity	6 kA
IP Rating	IP20
Modules	3 Module
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	30 deg C
Terminal Type	Screw
Tightening Torque	2.8 Nm
Voltage	415 Volt
Width	52.5 mm
