Hager Safety Switch RCCB Type A 4Pole 100A 6kA 30mA 4Module 72mm DIN Rail Mount

Description

Safety Switch RCCB Type A, 100 Amp, 50 Hz, 6 kA Interrupt Capacity, 30 mA Trip Sensitivity, 4 Modules, 72mm Module Width, 4 Poles, Screw Terminal, IP20, DIN Rail, 2000 Cycles, 4000 Cycles Mechanical Durability,-25 to 40 deg C, 86mm Height x 70mm Width x 70mm Depth

Key Specifications

Barcode (EAN-13)	3250611644989
SKU	HAGCD485T
Brand	Hager
Product Type	Safety Switches RCCB

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	CD485T
Current	100 Amp
Depth	70 mm
Height	86 mm
Electrical Life	2000 Cycles
Frequency	50 Hz
Interrupt Capacity	6 kA
IP Rating	IP20
Mechanical Durability	4000 Cycles
Modules	4 Module 72mm
Mounting Method	DIN Rail
Number Of Poles	4 Pole
Terminal Type	Screw
Temperature	-25 to 40 deg C
Width	70 mm
Trip Sensitivity	30 mA
