Austech Flexible Wire Single Insulated 1 Core 25mm 0.6/1kV Plain Copper V90HT PVC Blue
Loading...
Description
Flexible Cable, 25 mm, Class 6 Copper, 0.6-1 kV, 1 Core, 784/0.2 mm Strands, 9.1 mm Overall Diameter, DC: 0.78 Ohm/km Conductor Resistance, V-90HT PVC Insulation, Blue Insulation, Unsheathed Sheath, Static -35 to 105 deg C
Key Specifications
| SKU |
ELESIPF25L500
|
|---|---|
| Brand |
ElectCables
|
| Product Type |
Flexible Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121500 |
| UOM | MTR |
| Vendor Product | SIPF25L500 |
| Conductor Resistance | DC: 0.78 Ohm/km |
| Conductor Size | 25 mm |
| Conductor Type | Class 6 Copper |
| Insulation Colour | Blue |
| Insulation Material | V-90HT PVC |
| Number of Cores | 1 Core |
| Overall Diameter | 9.1 mm |
| Sheath Material | Unsheathed |
| Stranding | 784/0.2 mm |
| Temperature | Static -35 to 105 deg C |
| Voltage | 0.6-1 kV |
