Eaton Time Delay Relay Programmable Digital 2P 2CO On Delay 1s-600Hr 100-240V

Description

Time Delay Relay Programmable Digital, 100-240 Volt AC, 6.5 VA, 2 Pole 2CO, Timing Function: On Delay, Timing Range: 1 sec-600 hr, 500000 Electrical, 50000000 Mechanical Cycles, -20 to 65 deg C, 40 mm Height, 36 mm Width, 74.9 mm Depth

Key Specifications

Barcode (EAN-13)	9321289490100
SKU	EATTRNP240AC
Brand	Eaton
Product Type	Time Delay Relays

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	20 time ranges and 10 timing functions Space-saving, compact package High repeat accuracy of ± 0.2% LED indication Standard 8 or 11-pin and 11-blade termination 2 Form C DPDT delayed output contacts
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	TRNP240AC
Contact Configuration	2 Pole 2 Changeover
Depth	74.9 mm
Height	40 mm
Operating Cycles	500000 Electrical/50000000 Mechanical Cycles
Power Rating	6.5 VA
Temperature	-20 to 65 deg C
Timing Function	On Delay
Timing Range	1 Second-600 Hours
Voltage	100-240 Volt AC
Width	36 mm
