Eaton Cutler Hammer Pushbutton Actuator Only 40mm Mushroom Head Metal Body k Non Illuminated Momentary 30.5mm Panel

chevron-left
loader
Loading...

Description

chevron-down
Pushbutton Actuator Only 40mm Mushroom Head Metal Body, Size: 30.5 mm, Non-Illuminated, Momentary Action, Mushroom Head, IP66, Mounting Diameter: 30.5 mm, Panel Mount, Zinc Die-Cast Housing, Red, 38.1 mm Diameter,For Bare Shaft Operators

Key Specifications

chevron-down
Barcode (EAN-13)
9321289327871
SKU
CUTT282
Brand
Eaton Cutler Hammer
Range Name
T Series
Product Type
P/B Actuators Mushroom

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Die-cast metal housings create robust and heavy duty devices that can endure repetitive and heavy handed use in industrial environment
  • IP66 rated for protection against dirt and moisture
  • The corrosion resistant E34 range can with stand extremely harsh environments
  • Contact blocks are colour coded, green for NO and red for NC to permit easy identification and troubleshooting
  • Up to 6 contact blocks can stack on each other, allowing for up to 12 circuits per operator
  • Heavy duty zinc die cast construction
  • Enclosed silver contacts with reliability nibs
  • All normally closed contacts have positive opening operation, normally closed contacts are forced open in the event of contact weld or spring breakage
  • Diaphragm seals with drainage holes
  • Grounding nibs on the operator casing
Standard Pack Size 1
UNSPSC Class 39122200
UOM EA
Vendor Product T282
Colour Red
Diameter 38.1 mm
Head Type Mushroom
IP Rating IP66
Mounting Diameter 30.5 mm
Mounting Method Panel
Please Note For Bare Shaft Operators
Operator Action Non-Illuminated Momentary Action
Size 30.5 mm
