Certech UTP Network Cable High Performance Cat6 4 Pair 23AWG HDPE/LSZH Blue 305M

Description

The CERTECH CAT 6 U/UTP cable consists of 4 x copper conductor twisted pairs separated by a pair divider for superior AXT performance, LSZH jacket, and a strength member for improved pulling tension. CERTECH CAT 6 cabling solutions support data transmission speeds of up to 1 gigabit per second (1 Gbps). When combined with CERTECH CAT 6 jacks and installed by a CERTECH certified installer, the permanent links exceed the performance criteria outlined in AS 11801 (1-6) and certifiable through CERTECH's 25 years Certified Warranty Program.

Key Specifications

SKU	CERNCC6LSZHBLUE
Brand	Certech

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	305 mtr CAT 6 Blue UTP Solid Cable Roll 250 MHz 100% Bare Copper Cable 23 AWG x 4P LSZH Jacket AS/CA S008:2010 Approved 4K UHD Ready
Standard Pack Size	1
UNSPSC Class	26121600
UOM	EA
Vendor Product	NCC6LSZHBLUE
Cable Type	Cat 6 UTP
Bend Radius	8 x OD/4 x OD
Conductor Diameter	0.56 mm
Conductor Resistance	9.38 Ohm/100m
Conductor Size	23 AWG
Conductor Material	Bare copper
Elongation	>=125 - >=100
Frequency Bandwidth	250 MHz
Insulation Material	HDPE
Pair Count	4
Outside Diameter	6.2 mm +/-0.4 mm
Sheath Colour	Blue
Sheath Material	LSZH
Sheath Thickness	0.55 mm +/-0.05 mm
Stranding	Solid
Temperature	40 to 75 deg C
