Certech F/UTP Shielded Network Cable High Performance Cat6A 4 Pair 23AWG HDPE/LSZH Blue 305M

chevron-left
loader
Loading...

Description

chevron-down
The CERTECH CAT 6A F/UTP cable consists of 4 x copper conductor twisted pairs and a LSZH jacket, separated by a pair separator and wrapped in an overall foil shield. Designed with a strength member for improved pulling tension and drain wire for earth continuity. CERTECH CAT 6A cabling solutions support data transmission speeds of up to 10 gigabits per second (10 Gbps). When combined with CERTECH CAT 6A jacks and installed by a CERTECH certified installer, the permanent links exceed the performance criteria outlined in AS 11801 (1-6) and certifiable through CERTECH's 25 years Certified Warranty Program.

Key Specifications

chevron-down
Barcode (EAN-13)
329517644
SKU
CERNCC6AFUTPBLUE
Brand
Certech

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • 305 mtr CAT 6A F/UTP reel in a box 500 MHz
  • 100% bare copper cable
  • 23 AWG x 4P
  • LSZH Jacket
  • Overall foil shield
  • Integrated pair separator
Standard Pack Size 1
UNSPSC Class 26121600
UOM EA
Vendor Product NCC6AFUTPBLUE
Conductor Material Bare copper
Cable Type Cat 6A F/UTP
Conductor Diameter 0.56 mm
Conductor Resistance 9.38 Ohm/100m
Bend Radius 8 x OD/4 x OD
Conductor Size 23 AWG
Elongation >=125 - >=100
Frequency Bandwidth 500 MHz
Insulation Material HDPE
Outside Diameter 7.4 mm
Pair Count 4
Screen Material Aluminium
Sheath Colour Blue
Sheath Material LSZH
Sheath Thickness 0.60 mm +/-0.05 mm
Stranding Solid
Temperature 20 to 75 deg C
