Bussmann US Fuse Link Fast Acting Bolt In 1200A 1000VAC/800VDC 200kA/50kA 3.5x6.81in

chevron-left
loader
Loading...

Description

chevron-down
US Fuse Link Fast Acting, 1000 VAC/800 VDC, 1200 Amp, Interrupt Capacity: 200 kA at 1000 VAC, 50 kA at 800 VDC, 135mm Fixing Centres, Bolt In Tag, Stud Mounting, 3.5 in Diameter x 6.81 in Length

Key Specifications

chevron-down
SKU
BUSFWJ-1200A
Brand
Bussmann
Range Name
North American
Product Type
Fuse Links

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Excellent DC performance
  • Low arc voltage and low energy let-through
  • Superior cycling capability
  • DC common bus, DC drives, power converters/rectifiers, reduced voltage starters
Standard Pack Size 1
UNSPSC Class 39121600
UOM EA
Vendor Product FWJ-1200A
Diameter 3.5in
Fixing Centres 135mm
Current 1200 Amp
Interrupt Capacity 200 kA @ 1000 VAC/50 kA @ 800 VDC
Mounting Method Stud
Tag Type Bolt In
Voltage 1000 Volt AC/800 Volt DC
