Belden 1583A U/UTP Data Cable Cat5e Multi-Conductor 4 Pair Non-Bonded 24AWG Polyolefin/PVC Red 1000M

chevron-left
loader
Loading...

Description

chevron-down
U/UTP Data Cable Cat5e 4 Pair Non-Bonded, 300 Volt RMS, 24 AWG, 200 MHz Bandwidth, 9.38 Ohm/100 mtr at 20 deg C Conductor Resistance, Cat5e U/UTP-Unshielded Cable, 4 Pair, Bend Radius: Installation: 48.260mm, 155.687 N Max. Pulling Force, Solid Bare Copper Conductor, Rip Cord Filler, Polyolefin Insulation, PVC Sheath, Red Sheath,-20 to 60 deg C, 1000 mtr Length, 4.826mm Outside Diameter

Key Specifications

chevron-down
SKU
BEL1583A002RED
Brand
Belden
Product Type
Cat5E Cable

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Standard Pack Size 305
UNSPSC Class 43223300
UOM MTR
Vendor Product 1583A 0021000
Cable Type Cat5e U/UTP-Unshielded
Bend Radius Installation: 48.260mm
Conductor Resistance 9.38 Ohm/100 mtr at 20 deg C
Conductor Size 24 AWG
Conductor Material Solid Bare Copper
Filler Material Rip Cord
Frequency Bandwidth 200 MHz
Insulation Material Polyolefin
Max. Pulling Force 155.687 N
Pair Count 4 Pair
Outside Diameter 4.826mm
Sheath Colour Red
Sheath Material PVC
Temperature -20 to 60 deg C
Voltage 300 Volt
