Siemens European Bottle Fuse Link Diazed Time Delay 2A 500VAC 50kA 500VDC 8kA 22.5x49mm
Loading...
Description
European Bottle Fuse Link Diazed Time Delay, AC Voltage: 500 VAC, DC Voltage: 500 VDC, 2 Amp, AC Interrupt Capacity: 50 kA, DC Interrupt Capacity: 8 kA, Class gG, Pink,-5 to 40 deg C Ambient, 6mm Cap Diameter, 22.5mm Diameter x 49mm Length, DIN Size DII
Key Specifications
| Barcode (EAN-13) |
9323952327652
|
|---|---|
| SKU |
SIE5SB211
|
| Brand |
Siemens
|
| Product Type |
Fuse Links
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 5 |
|---|---|
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | 5SB211 |
| AC Interrupt Capacity | 50 kA |
| AC Voltage | 500 Volt AC |
| Cap Diameter | 6 mm |
| Colour | Pink |
| Current | 2 Amp |
| DC Interrupt Capacity | 8 kA |
| DC Voltage | 500 Volt DC |
| Dimensions | 22.5 mm Diameter x 49 mm Length |
| Standard Reference | DIN Size DII |
| Temperature | -5 to 40 deg C Ambient |
| Utilisation Category | Class gG |
