Garland Jack Outlet Mechanism Cat5e UTP RJ45 T568A/B White For Clipsal Style Faceplates

Description

Jack Outlet Mechanism Cat5e UTP RJ45, Solid: 22-24 AWG, RJ45 Connector, Cat5e UTP Cable, >100 MOhm Insulation Resistance, 20 mOhm Contact Resistance, 25 lb Plug Retention Force, 100 MHz Bandwidth, IDC Termination, Wiring Scheme: T568A/B, Flammability: UL94V-0, Thermoplastic Housing, Phosphor Bronze Contact Base, Gold over Nickel Contact Plating, White

Key Specifications

Barcode (EAN-13)	9329849020187
SKU	GARMT54501C-TUB
Brand	Garland

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Fitted with Krone type IDC connectors HPM or Clipsal style
Standard Pack Size	50
UNSPSC Class	39121400
UOM	EA
Vendor Product	MT54501C-TUB
Cable Type	Cat5e UTP
Colour	White
Conductor Size	Solid: 22-24 AWG
Connector	RJ45
Contact Plating Material	Gold over Nickel
Contact Base Material	Phosphor Bronze
Contact Resistance	20 mOhm
Flammability	UL94V-0
Frequency Bandwidth	100 MHz
Housing Material	Thermoplastic
Insulation Resistance	>100 MOhm
Termination Type	IDC
Wiring Scheme	T568A/B
