Electra 16mm SDI Cable Red 100mtr

Description

SDI Cable, 16 mm, Annealed Copper, 450-750 Volt, 1 Core, 1x7/1.7 mm Strands, 9.4 mm Overall Diameter, 100 mtr Length, 40 mm Bend Radius, 1 mm Insulation Thickness, 1 mm Sheath Thickness, DC: 1.15 Ohm/km AC: 1.4 Ohm/km Conductor Resistance, Red Core, V-90 PVC Insulation, 3V-90 PVC Sheath, White Sheath, 90 deg C, AS/NZS 5000.2 AS/NZS 1125 AS/NZS 3808

Key Specifications

SKU	ELCSDI1160V-RD/WH
Brand	Electra
Product Type	SDI Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	SDI1160V-RD/WH
Bend Radius	40 mm
Conductor Resistance	DC: 1.15 Ohm/km - AC: 1.4 Ohm/km
Conductor Size	16 mm
Conductor Type	Annealed Copper
Core Colours	Red
Insulation Material	V-90 PVC
Insulation Thickness	1 mm
Number of Cores	1 Core
Overall Diameter	9.4 mm
Sheath Colour	White
Sheath Material	3V-90 PVC
Sheath Thickness	1 mm
Standards	AS/NZS 5000.2 AS/NZS 1125 AS/NZS 3808
Temperature	90 deg C
Stranding	1x7/1.7 mm
Voltage	450-750 Volt
